| 구분 |
구성
소선수 |
강연선 계산
바깥지름
(mm) |
강연선 계산
단면적
(mm²) |
강연선 인장하중 TON |
단위중량
kg/m
(참고값) |
| 호별 |
표준
소선지름 mm |
1종 |
2종 |
3종 |
| 1호 |
3/2.90
3/3.20
3/3.50
3/4.00
3/4.30
3/4.50 |
6.2
6.9
7.5
8.6
9.3
9.7 |
19.8
24.1
28.9
37.7
43.6
47.7 |
2.28
2.78
3.32
4.34
5.01
5.49 |
1.64
2.00
2.39
3.12
3.61
3.95 |
1.28
1.56
1.86
2.43
2.81
3.08 |
156
190
228
298
344
377 |
| 2호 |
7/1.00
7/1.20
7/1.40
7/1.60
7/1.80
7/2.00
7/2.30
7/2.60
7/2.90
7/3.20
7/3.50
7/3.80
7/4.00
7/4.30
7/4.50
7/5.00 |
3.0
3.6
4.2
4.8
5.4
6.0
6.9
4.8
8.7
9.6
10.5
11.4
12.0
12.9
13.5
15.0 |
5.5
7.9
10.8
14.1
17.8
22.0
29.1
37.1
46.2
56.3
67.47
79.3
88.0
102.0
111.2
137.5
|
0.36
0.91
0.24
1.62
2.04
2.52
3.34
4.27
5.31
6.57
7.75
9.15
10.1
11.7
12.8
15.8 |
0.455
0.655
0.89
1.16
1.47
1.82
2.41
3.08
3.83
4.66
5.58
6.57
7.28
8.41
9.20
11.40 |
0.354
0.51
0.694
0.694
0.96
1.15
1.42
1.87
2.39
3.63
4.34
5.11
5.66
6.54
7.16
8.85 |
43.5
62.7
85.3
111
141
174
230
294
366
446
533
629
697
805
882
1090 |
| 3호 |
19/1.60
19/1.80
19/2.00
19/2.30
19/2.60
19/2.90
19/3.20
19/3.50
19/4.00 |
8.0
9.0
10.0
11.5
13.0
14.5
16.0
17.5
20.0 |
38.2
48.2
59.7
78.9
102
126
153
183
239 |
4.29
5.44
6.72
8.89
11.35
14.1
17.2
20.6
26.8 |
3.09
3.92
4.84
6.41
8.17
10.16
12.4
14.8
19.3 |
2.41
3.04
3.76
4.99
6.35
7.93
9.64
11.5
15.05 |
304
384
474
627
802
997
1210
1450
1900 |
